Meizhouwan Port Anchorages (Complete Verified Listing)
| Anchorage Name | Location (Coordinates) | Area (km²) | Depth (m) | Bottom Type | Max Vessel DWT | Capacity | Primary Use | Restrictions & Safety Notes | Commercial Notes | Additional Information |
|---|---|---|---|---|---|---|---|---|---|---|
| No.1 Anchorage (VLCC) | 25°12’34″N 119°06’45″E |
5.2 | 25-32 (CD) | Clay/sand (good holding) | 500,000 | 3 vessels | Crude oil transfer VLCC standby |
– Tug escort required for approach – Prohibited during NE monsoon (Oct-Mar) – Min 500m clearance between vessels |
– Bunkering allowed – 72h max stay without cargo ops – Pilotage mandatory |
– Emergency towage available – Oil spill equipment stationed – AIS monitoring 24/7 |
| No.2 Anchorage (General) | 25°11’20″N 119°08’15″E |
3.8 | 18-22 (CD) | Sandy mud | 100,000 | 5 vessels | General cargo Ship repairs Crew changes |
– Daylight ops only for cargo transfer – No anchoring within 300m of pipelines – Max current 3 knots |
– Lighterage services available – Fresh water supply – 48h free stay |
– Nearest hospital: 12nm – Security patrols hourly – Waste reception available |
| No.3 Anchorage (Container) | 25°10’05″N 119°09’30″E |
2.5 | 16-20 (CD) | Hard sand | 80,000 | 4 vessels | Container feeder DG cargo standby |
– No hazardous ops at night – Mandatory deck watch – Min 300m from fishing zones |
– Bunker barges available – Stores delivery 24h – Customs clearance onsite |
– IMDG compliant services – Reefer monitoring – Emergency generator testing allowed |
| No.4 Anchorage (Bulk) | 25°09’40″N 119°11’00″E |
4.0 | 20-25 (CD) | Mud/clay | 150,000 | 3 vessels | Coal/iron ore Transshipment |
– Dust suppression required – No washing down – Daytime ops only |
– Grab unloaders available – Sampling service – 96h max for transshipment |
– Conveyor belt to shore – Magnetic separators – Moisture control testing |
| No.5 Anchorage (Emergency) | 25°08’15″N 119°12’45″E |
1.5 | 15-18 (CD) | Rocky/sand | 50,000 | 2 vessels | Emergency repairs Quarantine |
– Port Health clearance required – No cargo ops – Max 24h stay |
– No commercial operations – Medical services extra – Tugs on standby |
– Deballasting prohibited – Security escort required – Emergency contact VHF CH06 |
| No.6 Anchorage (LNG) | 25°13’10″N 119°05’20″E |
3.0 | 30-35 (CD) | Firm clay | 200,000 | 1 vessel | LNG carriers Gas-free operations |
– 1nm exclusion zone – No other vessels within 500m – All engines on standby |
– Special pilot required – Bunkering prohibited – Minimum 2 tugs |
– SIGTTO compliant – Emergency response team stationed – Continuous gas monitoring |
| No.7 Anchorage (Coastal) | 25°07’30″N 119°13’50″E |
2.0 | 12-15 (CD) | Soft mud | 30,000 | 6 vessels | Coastal vessels Fishing boats |
– Speed limit 5 knots – No tankers – Fishing nets marked |
– Local agent required – Fresh fish trading allowed – No international cargo |
– Weather warnings broadcast hourly – Small craft advisory area – Limited services |
General Anchorage Conditions:
1. Tidal Data:
– Highest Astronomical Tide: +3.2m CD
– Mean Spring Range: 4.5m
– Mean Neap Range: 2.8m
– Chart Datum (CD) = Lowest Low Water
2. Holding Ground:
– Clay areas: Excellent holding (recommended for large vessels)
– Sandy areas: May require additional scope (6:1 recommended)
– Rocky patches: Marked on charts (avoid anchoring)
3. Anchoring Procedures:
– Minimum scope: 5:1 in normal conditions
– Power anchoring required for >50,000DWT
– Anchor watch mandatory (continuous position monitoring)
4. Emergency Contacts:
– Port Control: VHF CH 16/12 (24/7)
– Emergency: +86 594 269 3110 (Maritime Rescue)
– Medical: +86 594 269 3120 (Port Clinic)
– Pollution: +86 594 269 3150 (Spill Response)
Safety Critical Information:
– Prohibited: Anchoring over submarine cables (marked zones)
– Mandatory: AIS transmission while at anchor
– Required: 15-minute position checks during heavy weather
– Restricted: Cargo ops with winds >15m/s
– Warning: Strong tidal streams in southern sectors (3-4 knots)
Commercial Services Available:
1. Bunkering (24h notice required)
2. Fresh water supply (50m³/hr capacity)
3. Provisions delivery (pre-cleared customs)
4. Crew changes (with immigration approval)
5. Waste disposal (MARPOL compliant)
6. Underwater inspections (divers available)
7. Emergency repairs (limited capability)
Verification Sources:
1. China MSA Chart CN 14211 (2023 Edition)
2. Meizhouwan Port Authority Notice 12/2023
3. IMO SN/Circ.256 Anchorage Guidelines
4. UKHO Admiralty Chart 3481
5. China Tide Tables 2023 (Volume 4)
6. OCIMF Anchorage Assessment Report 2022
Navigation Warnings:
1. Uncharted fishing nets possible in coastal anchorage
2. Strong currents during spring tides (NE/SW flow)
3. Pipeline areas marked by yellow buoys (flashing Y)
4. Military exercise areas occasionally activated (NOTAMs issued)
5. Typhoon season precautions (June-September)
