In its most recent “Good Catch” – a series where the American Club provides valuable lessons learned from incidents – the Club refers to an incident regarding a bollard that was overloaded with multiple mooring lines.
The incident
A large container vessel had just begun cargo operations. Approximately 2 hours later, the bollard holding the bow lines was pulled out of the dock. The bow of the vessel swung outboard slightly, and the stern swung into the dock. Fortunately, the forward spring lines held and stopped the swing. The stern of the vessel contacted the fendering system but neither the vessel nor the fenders were damaged. The crew was subsequently able to re-secure the bow lines to different bollards.
Upon investigation, the four bow lines from the vessel had all been attached to the same bollard, the one that failed. The two forward spring lines were both attached to a different bollard. The two aft spring lines were both attached to yet another bollard. The four stern lines were paired to two different bollards astern of the vessel.
The Master explained that the while mooring, their normal practice was to place no more than two mooring lines on each bollard, but the pilot and line handlers had attached all four to the same bollard because a container crane was partially blocking access to the next bollard forward that would have otherwise been used. The Master said he deferred to the judgement of the pilot and line handlers. At the time of the bollard failure, the wind was mild, and the current was minimal.
Credits: American Club
Probable Cause
Inspection of the bollard indicated that some of the bolts attaching the bollard to the dock had sheared and some of the bolts were pulled out of the mounting intact. Each of the four bow lines was on a self-tensioning mooring winch. The combined load of the four winches together exceeded the bollard’s rated load. The Master indicated that he did not know the rated load of the bollard and had just assumed it was adequate since the pilot and line handlers placed all four bow lines on it.
