| Terminal Name | Berth Name | Length (m) | Depth (m) | DWT Capacity | Max LoA (m) | Berth Type | Shore Cranes | Safe Working Load (SWL) | Main Cargo | Certification Status |
|---|---|---|---|---|---|---|---|---|---|---|
| Itozaki General Cargo Terminal | Berth 1 | 120 | 7.5 | 5,000 | 100 | Concrete Dolphin | 1 × IHI CCH500 Mobile Crane (Serial No. CCH5-2018-042) |
20 tons at 10m radius (Cert. No. LIFT-2022-8876) |
General cargo, timber | MLIT Class C Valid until 2025-03-31 |
| Berth 2 | 80 | 5.0 | 3,000 | 70 | Steel Pile Pier | None | N/A | Coastal vessels | MLIT Class D Under fender replacement (Notice 2023-087) |
|
| Berth 3 | 60 | 4.0 | 1,500 | 50 | Timber Dolphin | None | N/A | Fishing supply | Local Gov. Certificate ITZ-PF-033 | |
| Berth 4 (Newly verified) |
90 | 6.0 | 4,000 | 85 | Composite Wharf | 2 × 10-ton jib cranes | 10 tons each | Construction materials | MLIT Class C (Provisional) | |
| Itozaki Fishing Terminal | Main Fishing Wharf | 150 | 4.5 | N/A | 30 | Concrete Wharf | None | N/A | Fishing vessels | JFS Standard A-2 Last inspected 2023-05-15 |
| Itozaki Fuel Terminal (New addition) |
Fuel Berth | 75 | 8.0 | 8,000 | 90 | Dolphin (Steel) | 1 × 15-ton hose crane | 15 tons (fluid transfer) | Bunker fuel | MLIT Class B ISO 13703 compliant |
Port Dolphins:
- North Dolphin: 15m diameter concrete, depth 8m, SWL 50 tons (MLIT inspection 2022-11-07, next due 2024-11)
- South Dolphin: 12m diameter concrete, depth 6m, SWL 30 tons (Concrete deterioration noted in 2023-04 survey, repair scheduled 2024 Q1)
- East Auxiliary Dolphin: 8m diameter steel, depth 5m, SWL 20 tons (For tug operations)
Mooring Buoys:
- No.1 Main Mooring Buoy: JPHA ref. SZ-112, depth 8m, DWT 10,000 (Yellow marker, last serviced 2023-03)
- No.2 Emergency Buoy: JPHA ref. SZ-113, depth 7m, DWT 5,000 (Red/white striped, 72hr limit, not for cargo ops)
- No.3 Fishing Mooring: Depth 5m, DWT 1,000 (Green marker, fishing vessels only)
Lighterage Facilities:
- Floating Barge “Itozaki-1”: 50-ton capacity, 12m × 6m, owned by Shizuoka Lighterage Co. (Cert. No. SLB-2022-554)
- Emergency Pontoon: 20-ton capacity, stored at western breakwater (Monthly inspection required)
- Fuel Transfer Barge: 30-ton capacity, dedicated to fuel terminal operations
Critical Operational Notices:
- Berth 2 fender replacement ongoing (Completion expected 2023-12-15) – Shizuoka PA notice No.2023-087
- North Dolphin winter restrictions: Max LOA 80m during Nov-Mar monsoon season – JCG Notice E2023-1543
- New depth restrictions at Berth 3: Minimum tide level reduced to 3.5m due to sedimentation – Effective 2023-10-01
Safety Equipment Inventory:
| Location | Firefighting | Oil Spill | Rescue |
|---|---|---|---|
| General Cargo Terminal | 2 × Foam stations | 200m containment boom | 2 × Life rings |
| Fuel Terminal | 3 × Dry chemical units | 500m boom + skimmer | Rescue boat |
